Pressure Gauge Transducer

Specifications:

• 230V/50HZ AC supply

Experiments:

To determine the calibration of pressure gauge

Transducer for Temperature Measurement

Specifications:

• PT 100
• Resistance value: 100 ohm at 0°C

Experiments:

Calibration of Transducer for Temperature Measurement

LVDT Transducer

Specifications:

• Micrometer resolution: 0.001 mm

Experiments:

To determine the calibration of LVDT

Strain Gauge

Specifications:

• Cantilever beam capacity: 1kg
• Width: 45mm
• Length: 355mm
• Thickness: 3mm

Experiments:

Calibration of strain gauge for force measurement

Thermocouple for Temperature Measurement

Specifications:

• J-type thermocouple probe

Experiments:

Calibration of Thermocouple for Temperature Measurement

Capacitive Transducer

Specifications:

• Angular displacement: 0° to 180°

Experiments:

Capacitive transducer for angular measurement

Resistance Temperature Detector

Specifications:

• Temperature range: 0° to 150°C

Experiments:

To determine the Calibration of Resistance Temperature Detector for Temperature Measurement.

Rotameter

Experiments:

Calibration of rotameter

Photo and Magnetic Speed Pickups

Experiments:

Calibration of Photo and Magnetic Speed Pickups
